SVC-8000VA New Smart LED Digital Meter, Servo-type AVR(built-in boost coil inside)
Retail price
0.0
Yuan
Market price
0.0
Yuan
Number of views:
1000
Product serial number
0000008SVC
Category
SVC 1P Servomotor-type AVR
Quantity
-
+
Stock:
0
1
Product description
Product Features:
This series adopt linear integrated circuit to form the control system, drive the contact voltage regulator to regulate automatically by controlling the servo motor, it is provided with delay, over-voltage, under voltage and over-current protection function which ensure the voltage stabilizer can supply safely; It has the advantage of high efficiency, low power consumption, high accuracy of stabilization, reliable and continuous work etc., good for in regions where the net voltage is much fluctuating, and hasthe following characteristics: 1). Servo motor control; 2). Wide range voltage regulate; 3). Automatic voltage regulation; 4). Smart LED digital meter display; 5). No additional waveform distortion; 6). With full protection functions: over-voltage, under-voltage, over-current, over-loading, over temperature, time-delay, short-circuit, auto. recovery etc. full protection functions.
Application Scope:
It is widely used in the electric equipments and facilities in housing, factory, school, shop, office, precision instrument for scientific experiment. And also, it is suitable for office equipment, test instrument, communication system, industrial equipment, armarium, domestic electric appliance and so on.
Technical Parameters:
|
Model |
SVC-8000VA |
|
Rated power |
8000VA, built-in boost coil inside |
|
Kinds |
Fully Automatic Voltage Regulation/Stabilizer(AVR/AVS) Servo motor controlled system, with smart LED digital meter display |
|
Phase No. |
Single Phase |
|
Input voltage range |
140~260VAC |
|
Output voltage |
220VAC |
|
Output precision |
± 2.5% |
|
Frequency |
50Hz/60Hz |
|
Efficiency |
>90% |
|
Response time |
≤1s(against 10% input voltage deviation) |
|
Ambient temperature |
-10℃~+40℃ |
|
Relative humidity |
<95% |
|
Dielectric strength |
1500V/1min. |
|
Insulation resistance |
≥2MΩ |
|
Waveform distortion |
No additional waveform distortion |
|
Protection |
Over-voltage, under-voltage, over-current, over-loading, over temperature, time-delay, short-circuit, auto. recovery etc. protection functions. |
|
Display |
Smart LED digital meter display |
|
Standing |
Desk shape |
|
Product quality |
Conform to CE, RoHs, SGS, ISO9001:2000 |
|
Warranty time |
18months |
|
Packing |
In standard export carton packages |
|
Gross weight(kg) |
|
|
Packing size(cm) |
|
|
Remarks: |
Customize option for specifications and availability, please feel free to contact CONPO Tech! |
